It is mainly used to crush, disperse, emulsify and mix liquid raw materials with different viscosity. Through the high-speed operation of the upper and lower serrations of the dispersion disc, the materials are sheared, impacted, crushed and dispersed at a high speed to achieve the functions of rapid mixing, dispersion and refinement.

Product Characteristics

1.It is widely used in scientific experiment, production simulation and new product development in the laboratory of industrial departments and researchinstitutes;

2.Digital display speed, manual liftand convenient operation;

3.It is multi-purpose.Replacing the sanding plate can play a role in grinding;

4.304 and 316L materials can be customized or sprayed according to customer requirements.

Working Principle

The toothing shaped circular dispersion discs disperse in the container at high speed to complete the solid-liquid dispersion, wetting, depolymerization and stabilization processes. The slurry is in a rolling annular flow, generating a strong vortex, and the particles on the blade surface fall to the bottom of the vortex in a spiral shape. The turbulent region was formed at the edge of the scattered disk 2.5 to 5mm. The slurry and particles were subjected to intense shear and shock. Two beams are formed outside the region, and the pulp is fully circulated and turned. The fluid at the bottom of the disperser is laminar flow, and the slurry layer of different flow rate disperses each other.

Technical Parameters

Product Application

It is suitable for the dispersion of small quantities of products in coatings, inks, petrochemical, pharmaceutical, food and fine chemical industries. It is widely used in the industrial production of scientific research, new product development and small batch products.

Applicable fields：Other fine chemical industry, Ink/dye, Food addition, Coating
